Supports battery-free operation and automatic activation of lithium batteries, adapting to various power consumption scenarios.
It is equipped with a 160A solar charger, supporting a higher PV voltage range (90~500VDC), and has a higher power generation efficiency.
Supports WiFi&GPRS remote monitoring, is compatible with iOS and Android, and is equipped with an e-touch button and one-click recovery function.
Optimize the charging strategy to effectively extend the battery life.
Built-in dust-proof kit, dual output channels ensure the long-term stable operation of the system.
| Product model | HJ-HIO4883S |
| Phase | 1-phase |
| Maximum PV input Power | 5400W+5400W |
| Rated Output Power | 8200W/8200VA |
| Maximum Solar Charging Current | 160A |
| AC Start-up Voltage /Auto Restart Voltage | 120-140VAC/180VAC |
| Acceptable Input Voltage Range | 90-280VACor170-280VAC |
| Frequency Range | 59~61+1HZ |
| Maximum AC Input Current | 48.2A |
| Nominal DC Voltage/Maximum DC Voltage | 360/500VDC |
| MPPT Voltage Range | 90-450VDC |
| Maximum input Current | 2/18A |
| Nominal Output Voltage | 220/230/240VAC |
| Output Waveform | Pure sine wave |
| Efficiency(DC to AC) | 90% |
| Nominal DC Voltage | 48VDC |
| Maximum Solar Charging Current | 160A |
| Maximum AC Charging Current | 140A |
| Maximum Solar+AC Charging Current | 160A |
| Nominal DC Voltage/Maximum DC Voltage | 360/500VDC |
| Start-up Voltage/Initial Feeding Voltage | 90VDC/120VDC |
| MPPT Voltage Range | 90-450VDC |
| Maximum Input Current | 2/18A |
| Nominal Output Voltage | 220/230/240VAC |
| Operating Temperature | -10℃~50℃℃ |
| Humidity | 5% to 95% Relative Humidity(Non~condensing) |
| Output Voltage Range | 195-253VAC |
| Nominal Output Current | 35.6A |
| AC Start-up Voltage/Auto Restart Voltage | 90-280VAC or 170-280VAC |
| Acceptable Input Voltage Range | 48.2A |
| Maximum AC Input Current | 140A |
| Dimension,D*W*H(mm) | 530*390*130 |
| Cartoon Dimension,D *W*H(mm) | 618*463*205 |
| Net Weight (kgs) | 14.2 |
| Gross Weight(kgs | 15.7 |
| Communication Port | RS232/RS485/WIFI/GPRS/LITHIUM BATTERY |
| Compliance Safety | CE |
Note: Specifications are subject to change without prior notice for product improvement. Data Sheet
