Selective Passivating Contact Technology
Topcon Technology Innovation, Key to Maximum Cell Efficiency
Bifacial modules are suitable for common photovoltaic power station application scenarios, such as wasteland, sandy land, cement ground, snow-covered ground, etc.
| Maximum Power (Pmax/W) | 710 | 715 | 720 | 725 | 730 |
| Open Circuit Voltage (Voc/V) | 48.67 | 48.82 | 48.97 | 49.12 | 49.27 |
| Short Circuit Current (Isc/A) | 18.24 | 18.31 | 18.38 | 18.45 | 18.52 |
| Voltage at Maximum Power (Vmp/V) | 40.89 | 41.04 | 41.19 | 41.34 | 41.49 |
| Current at Maximum Power (Imp/A) | 17.37 | 17.43 | 17.48 | 17.54 | 17.60 |
| Module Efficiency (%) | 22.86 | 23.02 | 23.18 | 23.34 | 23.50 |
| Operating Temperatur | e -40° C~+85° C | ||||
| Maximum System Voltage | 1000/1500V | ||||
| STC (Standard Testing Conditions): lrradiance 1000W/m2, Cell Temperature 25℃ , AM1.5 | |||||
| Maximum Power (Pmax/W) | 534 | 538 | 542 | 546 | 550 |
| Open Circuit Voltage (Voc/V) | 45.77 | 45.92 | 46.07 | 46.22 | 46.37 |
| Short Circuit Current (Isc/A) | 14.98 | 15.04 | 15.10 | 15.14 | 15.23 |
| Voltage at Maximum Power (Vmp/V) | 37.81 | 37.96 | 38.11 | 38.26 | 38.41 |
| Current at Maximum Power (Imp/A) | 14.13 | 14.18 | 14.23 | 14.28 | 14.32 |
| NMOT (Nominal Moudule Operating Temperature): lrradiance 800W/m2, Ambient Temperature 20℃ , AM1.5, Wind Speed 1m/s. | |||||
| 5% | Maximum Power (Pmax/W) | 746 | 751 | 756 | 761 | 767 |
| Module Efficiency (%) | 24.00 | 24.17 | 24.34 | 24.51 | 24.68 | |
| 15% | Maximum Power (Pmax/W) | 817 | 822 | 828 | 834 | 840 |
| Module Efficiency (%) | 26.28 | 26.47 | 26.66 | 26.84 | 27.03 | |
| 25% | Maximum Power (Pmax/W) | 888 | 894 | 900 | 906 | 913 |
| Module Efficiency (%) | 28.57 | 28.77 | 28.97 | 29.17 | 29.38 |
| Cell Type | 210×105mm Mono |
| Cell Orientation | 132(6×22) |
| Module Dimensions | 2384×1303×33mm |
| Weight | 37.5kg |
| Front Glass | 2.0mm high transmittance, reinforced glass |
| Rear Glass | 2.0mm part of the structure is grid-like white ceramic glass |
| Frame Material | Anodized aluminum alloy |
| Junction Box | Protection class IP68 |
| Cable | 4.0 mm2 positive pole: 250mm negative pole: 300 mm wire length can be customized |
| Temperature Coefficient (Pm) | -0.290%/℃ |
| Temperature Coefficient (Voc) | -0.250%/℃ |
| Temperature Coefficient (Isc) | 0.045%/℃ |
| NMOT (Nominal Moudule Operating Temperature) | 41±3℃ |
| Transportation methodsper pallet | Number of modules per cabinet | Number of modules |
| 40HQ container | 594 pcs | 33 pcs |
Note: Specifications are subject to change without prior notice for product improvement.
N-type MBB half cut technology, improve energy density, bring higher power output. High Bifacial Factor, up to 25% extra power generation
Passed TUV Salt & Ammonia corrosion test, and 2400Pa wind load, 5400Pa snow load test, higher reliability
Higher power generation compare with standard module in cloudy, foggy and low light condition
First year power degradation <1.0%，year 2-30 power degradation <0.40% each year
Passivated contact cell technology for higher power generation in operating
O-type cells with boron-oxide-free composite LID to increase module power generation
