Equipped with 75 51.2V/314Ah battery PACKs, the battery system includes BMS (Battery Management System), which can monitor the battery status in real time.
AC220V, DC48V, -12V.
EMS (Energy Management System) is integrated in the convergence control cabinet and the electric control cabinet to achieve precise control of the charging and discharging process of the energy storage system, optimisation of energy distribution and efficient management of the parallel convergence.
Equipped with an intelligent monitoring platform containing access control system and environment monitoring system, it can monitor the entry and exit of the personnel in the container as well as the temperature, humidity and other environmental parameters in real time, so as to ensure that the equipment operates in a suitable environment.
Adopting floor-standing integrated air-conditioning system with a rated cooling capacity of 20KW, together with the homemade air-conditioning duct system, it can accurately control the temperature inside the container to ensure that the batteries work in the appropriate temperature zone.
| Model | HJ-G500-1200F |
| Container System | 20ft container (6058*2438*2896mm) |
| Battery System (with BMS) | 75 51.2V/314Ah battery PACKs, total battery capacity 1205.760KWh |
| PCS | 500KW, off-grid and grid-connected optional |
| Convergence control cabinet | EMS system, parallel convergence system |
| Electric Control Cabinet | EMS system, AC power distribution system |
| Fire Fighting System | Containing fire protection cabinet, fire control cabinet, fire protection host, fire protection gas cylinder, do not enter sign, sound and light alarms |
| Monitoring System | Containing access control system, environmental monitoring system |
| Air Conditioning System | Floor-standing integrated machine, rated cooling capacity 20KW, including air conditioning duct system |
Note: Specifications are subject to change without prior notice for product improvement. Data Sheet
Power grid peak shifting and frequency regulation, industrial and commercial standby power, microgrid construction.
